ASTM A182 Stainless Steel Flanges

introduction

ASTM A182 is mainly used to specify the material, manufacturing process and performance requirements of forged or rolled alloy steel and stainless steel pipe fittings, flanges and other components for high temperature use.

ASTM A182 Material Standard:
Stainless steel: such as F304/L, F316/L, F317/L, F347, etc.
Duplex stainless steel and super duplex stainless steel: such as F51 (UNS S31803), F53 (UNS S32750), etc.

ASTM A182 forged flange types:
Weld neck flange (WN), socket flange (SW), slip-on flange (SO), threaded flange (TH), blind flange (BL), long weld neck flange (LWN), loose joint flange (LAPJ) SAE flange types.

Size range:
1/2 inch - 24 inches. For weld neck flange (WN) and blind flange (BL), the size can reach 60 inches.

ASTM A182 Pressure Rating:
ASME Flanges: Class 150#, 300#, 600#, 900#, 1500#, 2500#.
API Flanges: Class 75, 150, 300, 600, 900.
JIS Flanges: JIS B2220 5K, 10K, 16K, 20K, 30K
DIN Flanges: 6 Bar, 10 Bar, 16 Bar, 25 Bar, 40 Bar.
BS 4504 Flanges: PN10, PN16

Data table

ASTM A182 Flange Range Specification

ASTM A182 Stainless Steel Flanges Specification	ASTM A182 / ASME SA182
ASTM A182 Stainless Steel Flange Manufacturing Process	Hot Forging / Rolling / Machining
ASTM A182 Flange Other Grades	202 / 304 / 304L / 304H / 309S / 310S / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc. UNS No. - UNS S30400, UNS S30403, UNS S31008, UNS S31620, UNS S31603, UNS S31603, UNS S31635, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904 EN No. - 1.4301, 1.4307, 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539
ASTM A182 Stainless Steel Flange Outer Diameter	1/2" NB TO 64" NB
ASTM A182 Stainless Steel Flange Pressure Class	Class 150#, Class 300#, Class 400#, Class 600#, Class 900#, Class 1500#, Class 2500# or As Per Custom Requirement PN 6, PN 10, PN 16, PN 25 and PN 40 etc
ASTM A182 Stainless Steel Flange Schedule	Sch 10s TO Sch XXS or As Per Custom Requirement
ASTM A182 Stainless Steel Flange Facing	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

company advantage

The standards of flanges mainly include ANSI B16.5, EN1092-1, SABA1123, JIS B2220, DIN, GOST, UNI, AS2129, API 6A, etc. Flanges of different types and standards are suitable for different application scenarios to meet specific needs.
For more information about large-diameter flanges or other types and prices, please feel free to contact us.
