904L Stainless Steel Plate

904L stainless steel plate (N08904, 14539) contains 14.0-18.0% chromium, 24.0-26.0% nickel, and 4.5% molybdenum in super austenitic stainless steel.
904L super austenitic stainless steel plate is a low-carbon, high-nickel, molybdenum austenitic stainless acid-resistant steel. It has good pitting resistance in neutral chloride ion media, as well as good crevice corrosion resistance and stress corrosion resistance. It is suitable for various concentrations of sulfuric acid below 70°C, and has good corrosion resistance in acetic acid of any concentration and any temperature under normal pressure, and mixed acid of formic acid and acetic acid.

Chemical Analysis

Weight % (all values are maximum unless a range is otherwise indicated)

Nickel	23.0 min.-28.0 max.	Silicon	1.00
Chromium	19.0 min.-23.0 max.	Phosphorus	0.045
Molybdenum	4.0 min.-5.0 max.	Sulfur	0.035
Copper	1.0-2.0 max.	Iron	Balance
Manganese	2.00

Mechanical Properties

Typical Values at 68°F (20°C) (minimum values, unless specified)

Yield Strength 0.2% Offset		Ultimate Tensile Strength		Elongation in 2 in.	Hardness
psi (min.)	(MPa)	psi (min.)	(MPa)	% (min.)	(max.)
31,000	220	71,000	490	36	70-90 Rockwell B

GNEE is equipped with 2 sets of 30-ton electric arc furnaces, 35-ton AOD refining furnaces, 30-ton LF, furnace double-stream continuous casting machine, German OBLF spectrometer and other advanced equipment.
GNEE has ultrasonic flaw detectors, eddy current flaw detectors, hydraulic testing machines, X-ray flaw detectors, direct reading spectrometers, nitrogen and oxygen analyzers, hydraulic testing machines, impact testing machines, automatic carbon and sulfur analyzers, endoscopes and other testing equipment with complete testing methods.
The main brands are TP321, TP316Ti, S32205, TP347H, TP316L, TP310S, TP304, TP304L, 321, S32750, 904L, C276, 254SMO, etc.

Q1. How do you control quality ?

A1: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS Verified.

Q2: What is the terms of packing?

A2: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.

Q3:What is your delivery time?

A3: For stocks, we could transport the goods to loading port within 7 days after we received your deposit

For production period, it usually takes about 15 days-30 days after receiving the deposit.
