2507 super duplex stainless steel plate is a ferrite-austenite duplex stainless steel, composed of two phases of austenite and ferrite, with high strength and excellent corrosion resistance.
Implementation standard: ASTM A240
Key Advantages
The yield strength and tensile strength of 2507 stainless steel plate can reach 450MPa and 620MPa respectively. It has high toughness and can withstand large impact and vibration.
Duplex 2507 stainless steel plate also has excellent corrosion resistance to inorganic acids such as sulfuric acid and hydrochloric acid, especially in chloride-containing environments.
Duplex 2507 Stainless Steel Plate field:
Oil and gas industry: used in offshore oil platforms, heat exchangers, pipelines and other equipment.
Chemical process: used to treat wastewater and waste gas containing corrosive substances.
Desalination: used in desalination plants, high-pressure reverse osmosis devices and seawater pipelines
| Specification | ASTM A240 Type 2507, A240 UNS S32750, A240 UNS S32760, SA 240 |
|---|---|
| Size |
Cold rolled: 0.5-6.4 mm Hot rolled : 3.0–10.0 mm |
| Thickness | 0.1 mm to 100 mm |
| Width | 10 mm - 2500mm |
| Length | 2m, 2.44m, 3m, 4m or as required |
| Finish | Hairline, 1D, Mirror, 2D, 2B, No.4, No.1, BA, 8K, SATIN, No.8, Brush |
| Ultimate Tensile Strength, ksi | minimum 116 |
|---|---|
| Yield Strength 0.2% Offset |
minimum 80 |
| ksi 0.1% Offset Yield Strength 0.2% | minimum 91 |
| Elongation in %, 2 inch | minimum 15 |
| Hardness | Maximum 32 |
| Impact Energy, | minimum 74 ft.-lbs. |
Why choose GNEE
GNEE has twelve 8-22 inch cold drawing unit production lines and supporting pickling, annealing and automatic grinding equipment. The production adopts a real-time online process display and tracking system to effectively ensure production time and quality. The annual production capacity is about 20,000 tons.
Contact us now for a free estimate.
.jpg)
.jpg)
Q: Can we visit your factory?
A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
Q: Can you provide OEM/ODM service?
A: Yes. Please feel free to contact us for more detail discussion.
Q.What is the ASTM equivalent of 1.4410?
A.DIN EN 1.4410 is equivalent to UNS S32750 (ASTM A182 F53). It is a 25% Cr super duplex stainless steel called SAF2507.
